2026 Ford F-150 Towing Guide: Capacity by Trim and Engine
Whether you're pulling a boat to the Hudson, a camper up to the Catskills, or a work trailer across the county, the F-150 has a setup for it. The trick is that trim level is only part of the story. Your towing number really comes down to engine, cab, bed length, axle ratio, drivetrain and whether you add the Tow/Haul Package. Here's how it all breaks down, straight from Ford's official specs.
Max towing by engine
| Engine | Max Conventional Towing | Max Payload |
|---|---|---|
| 2.7L EcoBoost V6 | 8,400 lbs | 1,775 lbs |
| 3.5L EcoBoost V6 | 13,500 lbs | 2,440 lbs |
| 5.0L Ti-VCT V8 | 12,800 lbs | 2,235 lbs |
| 3.5L PowerBoost Full Hybrid V6 | 12,400 lbs (4x2) / 11,600 lbs (4x4) | 1,740 lbs |
| 3.5L High Output EcoBoost V6 (Raptor) | 8,200 lbs | 1,405 lbs |
| 5.2L Supercharged V8 (Raptor R) | 8,700 lbs | 1,410 lbs |
The top ratings for the 3.5L EcoBoost, 5.0L V8 and PowerBoost all require Tow/Haul Package and Max Tow Axle upgrade. One more thing to keep in mind: horsepower, torque, payload and towing are independent attributes and may not be achieved simultaneously.
Engine availability and top tow rating by trim
| Trim | Available Engines | Highest Engine Rating Available |
|---|---|---|
| XL | 2.7L EcoBoost, 5.0L V8, 3.5L EcoBoost | 13,500 lbs (3.5L EcoBoost) |
| STX | 2.7L EcoBoost, 5.0L V8, 3.5L PowerBoost | 12,800 lbs (5.0L V8) |
| XLT | 2.7L EcoBoost, 5.0L V8, 3.5L EcoBoost, 3.5L PowerBoost | 13,500 lbs (Ford's named max tow config) |
| Lariat | 5.0L V8, 3.5L EcoBoost, 3.5L PowerBoost | 13,500 lbs (3.5L EcoBoost) |
| Tremor | 5.0L V8, 3.5L EcoBoost | 10,600 lbs (3.5L EcoBoost, Tremor rating) |
| King Ranch | 3.5L EcoBoost, 3.5L PowerBoost | 13,500 lbs (3.5L EcoBoost) |
| Platinum | 3.5L EcoBoost, 3.5L PowerBoost | 13,500 lbs (3.5L EcoBoost) |
| Raptor | 3.5L High Output EcoBoost | 8,200 lbs |
| Raptor R | 5.2L Supercharged V8 | 8,700 lbs |
A quick heads up: the top ratings above apply to the best-equipped configurations. Ford notes that your specific vehicle's tow capability could be reduced based on weight of selected trim series and option content. So a loaded Platinum won't always match an XLT with the same engine. That's exactly why it's worth sitting down with our team to spec the right truck. Ford
What you need to hit max towing
For gas trucks, Ford requires the Tow/Haul Package (53T) plus the optional Max Tow Axle for trailers over 11,600 lbs. For the hybrid, the threshold is for trailers over 10,800 lbs. Ford also warns that your New Vehicle Limited Warranty may be voided if you tow without them. 2026 Ford F-150 Towing Information +2
The Tow/Haul Package includes the integrated trailer brake controller and either the 3.55 or 3.73 e-lock rear axle depending on the powertrain. Ford
The hitch receiver also changes with the package. A 2" hitch receiver rated at 11,600 lbs. is standard. Max Tow Axle includes 2" reinforced receiver rated at 14,000 lbs. Ford
Weight rules worth knowing
- Use weight distribution over 5,000 lbs. Do not exceed trailer weight of 5,000 lbs. when towing without a weight-distribution system. Ford
- Tongue weight should be about 10% of the trailer. Trailer tongue load weight should be 10% of total loaded trailer weight. For 5th-wheel and gooseneck trailers, the king pin load should be 15% of total loaded trailer weight. FordFord
- Count people and cargo against payload. Your payload has to cover the tongue weight, your passengers and whatever's in the bed.
- Watch the trailer's frontal area. Ford's limit is 55 sq. ft. for vehicles with Trailer Tow Rating of 7,700 lbs. or less, 65 sq. ft. for vehicles with Trailer Tow Rating of 7,701 lbs. and greater and 75 sq. ft. for all 5th-Wheel and Gooseneck applications. Ford
- Heading into the mountains? At elevation, Ford recommends you reduce Gross Vehicle Weight (GVW) and Gross Combination Weight (GCW) by 2% per 1,000 ft. elevation. Ford
- Bring a matching spare. A conventional, identical full-size spare tire is required for trailer towing. Ford
- Raptor owners, skip the 5th-wheel. 5th-wheel towing is not recommended for Raptor model. Ford
Towing tech that makes life easier
Every F-150 comes with trailer sway control, a 7-wire harness, a hitch receiver, a transmission oil cooler and Tow/Haul mode. The Lariat and up add a 360-Degree Camera, Pro Trailer Backup Assist and Pro Trailer Hitch Assist as standard.
With Pro Trailer Backup Assist, you simply rotate in the direction you want the trailer to go, and it'll move your truck and trailer into position. Pro Trailer Hitch Assist steers, accelerates and brakes for you, as it guides your truck into place for easy hitching to your conventional trailer.
Towing FAQ
What's the max towing capacity of the 2026 F-150?
13,500 lbs with the 3.5L EcoBoost V6. Ford's top configuration is the XLT SuperCrew 4x4 with the 6.5' box, the Tow/Haul Package and the Max Tow Axle.
How much can the F-150 hybrid tow?
Up to 12,400 lbs on a 4x2 SuperCrew and up to 11,600 lbs on a 4x4, when properly equipped.
How much can the F-150 Tremor tow?
Up to 10,600 lbs with the 3.5L EcoBoost and 10,000 lbs with the 5.0L V8.
Do I need the Tow/Haul Package?
If you're towing over 11,600 lbs with a gas engine, or over 10,800 lbs with the hybrid, yes. You'll need the Tow/Haul Package and the Max Tow Axle.
Where do I find my truck's exact ratings?
See label on doorjamb for carrying capacity of a specific vehicle. The axle code is on the same Safety Compliance Certification Label. Or just stop by, and we'll walk through it with you!
